FAT S Electric Folding Bike

  • Merry Gold

  • 36V 350W-500w

  • Li-ion 36V 10.4AH


FAT S Electric Folding Bike

Many city residents live in tight quarters and small apartments. Let's say a customer is strapped for space but still needs an effective way to get around town. A brilliantly designed folding E-bike collapses into a compact unit for easy storage, then easily unfolds to take them wherever they need to go. They can even be carried onto public transportation! See our range below.


Motro Type Motro Type Rear   Drive
Motor Power 36V250w ( EU) 48V500W ( 750w is optional)
Working Style PAS only ( EU) PAS & Throttle, 1:1 intelligent PAS
Controller 36V 18A ( EU) /48V18A(500W)/48V25A(750W)
Display White and Black LCD display
Light F: LED light
Battery Lithium battery 36V13ah/15ah/20ah/48V13/15AH/20ah
Charger 50-60HZ, AC90-240V
Mechanical Frame Aluminum Alloy 6061# / Foldable
Tyres Front: 20” * 4.0inch, Rear: 20” * 4.0inch
Rim Alloy
Brake F/R: Disc brake
Brake Lever Tektro Cut-off while braking
Front Fork steel fork with painting ( suspension fork is optional)
Derailleur Shimano 7 speed tourney
Other Handlebar&Stem&Seat post: Alloy
Performance Max Speed 25KM/H(EU) ; 30km/h ( 500w); 40km/h ( 750w)
Range 35KM-50KM
Max Loading 110KG
Climbing ≥10% (36V250w) ( EU) ≥20%
Charge Time 5-6H / Cricle Life > 600times
Packing   Info Available Colors Customized, Y.S color code
Body Size
Packing Size 144 *28*78CM
N. W/ G.W 37KG/42KG
Container Load 20"- 96PCS 40"-211PCS
